Diesel Fuel Injection Engine Diagnostics Troubleshooter Chart

Possible Diesel Engine Faults

Fault Code	Symptoms	Possible Cause
	Engine will not Crank	Low starter battery voltage. Ignition switch faulty or wiring. Starter motor or related wiring fault. Engine immobiliser locked. Engine may be seized Engine may be hydraulically locked due to fluid leak in to cylinders
	Engine Cranks but will not Start	Engine immobiliser locked. No fuel in the tank. Incorrect fuel in the tank. Fuel supply line blocked Fuel primer pump inoperative. Air entering fuel system. Pre heater (glow) plugs / relay / wiring faulty. Incorrect valve timing. Incorrect Injection pump timing. High pressure fuel injection pump faulty. No engine Rpm signal from ckp (may set fault code P0335) No camshaft sensor signal (cylinder phasing error, may set fault code P0341) Fuel Injectors faulty (may set P0200 or related fault code) Fuel injector pipes incorrectly fitted. High pressure system loss of pressure. Common rail pressure fault (may set P087 or P088 fault code) Failure of an electronic control system sensor / wiring. Fault codes logged on Diesel control unit (DCU) preventing startup. Failure of Diesel control unit . Air intake System blocked / restricted. Exhaust system blocked or restricted. Engine condition causing low compression pressure. Diesel injection pump not delivering fuel
	Engine Starts then stops within a few seconds	Restricted fuel supply. Check fuel tank, pipes and filters. Air entering fuel system. Immobiliser fault. Faulty or incorrect ESOS (engine stop solenoid) or ELAP. Electronic engine control fault. Test ECU and wiring. Air intake restriction. Exhaust system blocked / restricted. EGR valve stuck or blocked.
	Unstable Idling	Fuel supply restriction. Air entering fuel system. Electronic control system or wiring fault. Blocked /leaking /inoperative fuel Injector. Mechanical Injection pump fault (possible pump phasing). Incorrect pump to engine timing. Valve timing or compression problem. Heater plug circuit fault. Air intake system fault. Exhaust partially blocked. Exhaust gas recirculation (EGR) system fault. Engine compression fault. Engine Misfire.
	Excessive mechanical noise.	Incorrect engine oil level Incorrect engine oil specification Insecure engine component / mechanical failure. Incorrectly fitted timing belt. Incorrect valve clearances. Insecure components. Incorrect pump / valve / engine timing. Incorrect fuel injector calibration / fault. Incorrect Injection pump calibration. Precombustion chamber loose in cylinder head. Excessive engine mechanical noise may be detected by the Knock sensor setting fault code P0325 Exhaust system blockage.
	Excess black exhaust smoke emission	Faulty / dirty fuel injectors. Incorrect injection pump to engine timing. Injection pump overfuelling / incorrect calibration. Fuel Injection pump excess fuel device fault. Electronic control system fault. Restricted air intake or air filter blocked. Engine not reaching operating temperature. Heater plug post heat fault. Turbocharger oil seals failing allowing engine oil to leak into air intake system. Low boost pressure from turbo or intake system leaks.
	Excess White / Grey smoke emission	Fuel injector opening pressure too low. Incorrect valve timing. Incorrect injection pump timing. Low cylinder compression pressure. Restricted air intake. Low turbocharger boost pressure due to worn turbo / intake system fault / boost control. Water entering combustion chambers due to head gasket failure, cylinder head or block cracked.
P0300, P0301, P0302, P0303, P0304, P0305, P0306, P0307, P0308,	Engine Misfire	Air entering fuel system. Fuel line restriction. Faulty fuel injector / calibration. Wiring fault. Incorrect valve timing. Incorrect valve clearance. Compression loss. Faulty Injection pump.
	Random engine acceleration	Engine gaining extra fuel from supplementary source, eg , mechanical pump boost control diaphragm leaking fuel into turbo through boost control pipework. Excessive engine oil level : Engine inducting engine oil & using as a fuel. Electronic control system fault. Faulty fuel injection pump. Accelerator linkage insecure. Throttle position actuator stuck or wiring fault
	Slow deceleration	Restricted fuel return line. Insecure accelerator linkage or return spring missing.
	Low or Insufficient power	Restricted fuel supply. Contaminated fuel. (Water in fuel, Petrol mixed in diesel, heating oil mixed in diesel, etc) Injectors faulty. Fuel Pump calibration fault or worn pump. Incorrect valve or fuel pump timing. Fuel pump stop solenoid not opening fully. Electronic diesel MPROP Solenoid sticking or dirty Accelerator linkage insecure or travel restricted. Electronic engine control system or wiring fault. Electronic diesel control system in limp home mode or restricted mode. Turbocharger system fault. Air mass or Airflow meter fault (may set P0100 fault code) Restricted exhaust system. Exhaust Gas Recirculation fault (may log ecu fault codes eg, P0400 ) Road speed limiter incorrectly set or system fault. Engine temperature fault. Vehicle braking system not releasing.
	Engine Overheating	Low coolant level, or coolant leakage, cooling system pressure loss,cooling pressure cap faulty. Water pump impellor failure Blocked radiator ; internally or airflow. Faulty viscous fan , or fan motor not operating , wiring fault. Incorrect injection pump calibration. Faulty fuel injectors. Incorrect injection pump timing , or electronic control system fault. Mechanical fault with engine, head gasket failure, cracked cylinder head, cracked cylinder block . Excessive engine load due to vehicle brakes sticking on etc.
	Engine will not shut off	Engine gaining a supplementary fuel supply. Ignition switch / wiring fault leaving fuel stop solenoid energised. Faulty fuel stop solenoid. Stop control linkage disconnected or broken.
P0100	Mass Air Flow circuit malfunction	First instinct of many technicians is to change the airflow meter but remember the key principle of the combustion engine which is basically a machine which pumps air. The P0100 fault code can have many causes including : Air flow meter electrical fault or Wiring Insufficient air flow past meter may be caused by leaking air intake pipework, turbocharger faults, restricted air intake, incorrect valve clearances, restricted exhaust system.
P0200	Fuel system fault codes typically related to fuel injectors or electrical circuits
P0300	Ignition system fault codes typically related to ignition or electrical circuits and misfires.
P0400	Exhaust system fault codes typically related to exhaust gas recirculation systems
P1564	Injection pump control module requests reduced fuelling
P1608	Injection pump watchdog signal lost - open circuit
P1608	Injection pump control module malfunction
